Contemporary home project for 12 x 30m grounds with pool or 12x25m without pool. This project was created for a family that does not like the construction of a complete house, but that maintains an idea of a dormitory in the upper floor to guarantee an intimacy and better to take advantage of the free spaces of the land. The organization of the environments provides for a natural separation of the dormitory with the social area of the house. On the tv room was designed a mezzanine which gives the street view and access to the couple's suite.
| Included items |
| Click the items below to see an example: |
 Low Floor see example |
| Cover Plan see example |
| Humanized Plan see example |
| Table Summary of Frames see example |
| Example Project in AutoCAD (allows changes) see example |
| Facade Elevations see example |
| Internal Cuts see example |
| 3D Facade Images see example |
| Foundation Plan see example |
|
BUY PROJECT READY
|
| Building area | 224 square meters |
| Width of the house | 9 metros |
| Length of the house | 18,17 meters |
| Width of terrain | 12 meters or greater |
| Length of terrain | 30 meters or greater |
| Bedrooms | 3 |
| Suites | 1 |
| Bathrooms | 3 |
| Garage | 2 vacancies |
| Frontal Retreat | 4 meters |
| Background recoil | 7,83 meters |
| Left indent | 1,50 meters |
| Right indent | 1,50 meters |
