This is a great example of a modern and functional floor plan, where living rooms are integrated and the intimate ones are separated from the social area by a corridor, giving more privacy to the residents. This house has two openings in the covered garage, integrated TV and dining room, and further to the kitchen, next to the laundry room and the gourmet area. In the intimate side are 3 bedrooms, the one of the couple with closet and suite.
| Included items |
| Click the items below to see an example: |
 Low Floor see example |
| Cover Plan see example |
| Humanized Plan see example |
| Table Summary of Frames see example |
| Example Project in AutoCAD (allows changes) see example |
| Facade Elevations see example |
| Internal Cuts see example |
| 3D Facade Images see example |
| Foundation Plan see example |
|
BUY PROJECT READY
|
| Building area | 165 square meters |
| Width of the house | 9 metros |
| Length of the house | 18 meters |
| Width of terrain | 12 meters or greater |
| Length of terrain | 25 meters or greater |
| Bedrooms | 3 |
| Suites | 1 |
| Bathrooms | 3 |
| Garage | 2 vacancies |
| Frontal Retreat | 5 meters |
| Background recoil | 2 meters |
| Left indent | 1,50 meters |
| Right indent | 1,50 meters |
